The RAD2X is the perfect plug and play low latency solution for connecting your Mega Drive 2 or Genesis 2 to a modern flat screen television. This is based on the same technology used in the RetroTINK2x with the added bonus of supporting RGB video, and unlike other all-in-one HD cable solutions the RAD2X correctly interprets the the 240p signal correctly and processes this as a progressive scan image and then line doubles this to 480p.
Requires a Male HDMI® to mini C HDMI® cable (not supplied).
Specifications:
- Formats: 240p/480i, 288i/576i, NTSC and PAL
- Input: RGB internally converted to YPbPr
- Built-in anti-aliasing LPF
- Output: mini HDMI® at 480p/576p (line-doubled mode)
- Default 4:3 Aspect Ratio
- Latency: About 53 microseconds
- Audio: 24-bit stereo
- Optional smoothing filter with mechanical ON/OFF switch
- No need for external power supply
- Fully shielded PACKAPUNCH cable from the console to the RAD2X
Compatible with following consoles:
- Sega Mega Drive 2 - All regions
- Sega Genesis 2
- Sega Genesis 3
- Sega Nomad
- Sega Pico
- Sega Multimega
- Sega CDX
Compatible with following PC Engine and TurboGrafx-16 add-ons.
- dbGrafx Booster TTP by db-electronics.
- Super SD System 3 by Terraonion.
- Engine Block AV (TurboBooster) from Stone Age Gamer.
- Krikzz EDFX.
Anything that uses a Genesis 2 / Megadrive 2 port can use this adapter!
With an adapter, this will also work with the following:
- Megadrive 1 / Genesis 1 / Master System
- SNK Neo Geo AES / CD / CDZ
- PC Engine duo and TurboGrafx-16 (RGB Modified only)
